Face Mill

AP SHELL TYPE ROUGH CUTTING END MILLS GD-00122

AP SHELL TYPE ROUGH CUTTING END MILLS GD-00122

Item No.: CO162220734
Send Enquiry

1.Products name：BAPTAP-RIGGD-ANGLE-SHOULDER-FACE-MILL-CUTTERS
2.Material: 40crmo
3. application:0.003mm
4.Place of Origin: Shandong, China (Mainland)
5.Package: Plastic box

6.Type: OM5005 MP91M OM4040 OST20

7.Payment: T/T, PayPal, Alibaba Trade Assurance
8.Package:Plastic box
9.Brand:GD-TOOLS

Produce features:
1.Use the anti-knocking tool steeel material quality.
2.After whole pre-hard.finshes again, two processing having the strain

GD-00122	AP SHELL TYPE ROUGH CUTTING END MILLS
规格/型号 Model	尺寸 Size(mm)				刃数 Teeth	刀片数 Blade number	刀片 Insert	螺丝 Screw	扳手 Wrench
	D	d	L1	L
	D	d	L1	L
AP-D50-d22-42M-3T-9Z	50	22	42	55	3	9	AP..1604	M4-10-5.7-60	T15
AP-D50-d22-42M-3T-12Z	50	22	42	55	4	12	AP..1604	M4-10-5.7-60	T15
AP-D63-d27-42M-4T-12Z	63	27	42	63	4	12	AP..1604	M4-10-5.7-60	T15
AP-D63-d27-45M-4T-12Z	63	27	45	66	4	12	AP..1604	M4-10-5.7-60	T15
AP-D50-d27-68M-4T-20Z	63	27	68	89	4	20	AP..1604	M4-10-5.7-60	T15
AP-D80-d32-54M-6T-24Z	80	32	54	90	6	24	AP..1604	M4-10-5.7-60	T15
AP-D80-d32-68M-5T-25Z	80	32	68	130	5	25	AP..1604	M4-10-5.7-60	T15
AP-D80-d32-70M-5T-25Z	80	32	70	85	5	25	AP..1604	M4-10-5.7-60	T15
AP-D80-d32-115M-6T-30Z	80	32	115	150	6	30	AP..1604	M4-10-5.7-60	T15
